The different excitation wavelengths are supplied by up to three internal laser and eventually by one external laser. The confocal microscope is coupled to a 460 mm focal length spectrograph equipped with a four interchangeable gratings turret. The LabRAM Aramis is an integrated confocal microRaman system. Raman can best be thought of as producing a precise spectral fingerprint, unique to a molecule or indeed and individual molecular structure or chemical bonding. This energy loss is characteristic for a particular bond in the molecule. The amount of energy lost is seen as a change in energy (wavelength) of the irradiating photon. With Raman spectroscopy, a laser photon is scattered by a sample molecule and loses (or gains) energy during the process. The Raman scattering technique is a vibrational molecular spectroscopy which derives from an inelastic light scattering process.
Bruker apex ii software software#
The APEX2 software features a redesigned start-to-finish graphical user interface (GUI) along with the optional Phase ID and Auto Structure software modules. The instrument is presently equipped with Mo-radiation and an Oxford Cryo-system low temperature system can be added to perform data collection down to 100K.īruker SMART APEX Software system provides the tools for complete small molecule structure determination. The instrument is producing data of quality for both routine structure determination and for high accuracy and high resolution data.ĭata collection can take from a couple of hours to a day depends of the crystal quality and crystal symmetry.
Its use has thus become an essential tool for new discovery. XR-SCD is one of the most powerful methods for generating vital information on the atomic arrangement into crystals and organized molecules. doi:10.BRUKER APEX II Diffractometer is an X-Ray Single Crystal Diffractometer (XR-SCD) based on a platform goniometer and equipped with an APEX II CCD Detector. Jansen: Reticular merohedral twinning within the La 9Sb 5O 5 structure family: structure of Pr 9Sb 5O 5, Sm 9Sb 5O 5 and Dy 9Sb 5O 5Īcta Crystallogr. Jansen: Structure of RbFeO 2, refined from a reticular pseudomerohedrally twinned crystal with six domainsĪcta Crystallogr. Jansen: Structures of incommensurate and commensurate compositeĪcta Crystallogr., Sect. Lab Report SC-XRD 46, Bruker AXS GmbH (2011). Nuss: Higher Dimensional Crystallography: Treatment of Composite Crystals Using Four Dimensions in Space Jansen: Modulated crystal structure of Pr 2SbO 2Īcta Crystallogr., Sect. Low temperature investigations for analysis of phase transitions, structure determination of temperature sensitive compounds, investigation of aperiodic structures und complex twinned crystals. Structural characterisation of new compounds with the help of X-ray diffraction methods on single crystals: Measurments of samples sensitive to air and moisture. Software for evaluation and analysis of modulated structures (commensurable and incommensurable).Video system for precise measuring of crystals (numerical absorption correction).Low temperature device: N-Helix, Oxford Cryosystems, temperature range 28 - 300 K.Measuring range: Maximum 2theta 145° (Cu), 120° (Mo).(Mo) and Incoatec Microfocus Source IµS (Cu), changeable use. Three circle diffractometer with conventional X-ray tube.Software for evaluation and analysis of any kind of twinned crystals.Low temperature device: Cryostream Plus, Oxford Cryosystems, temperature range 80 - 500 K.
